Casa RS

The normal line of sight of the human eye is 30 degrees above to 60 degrees below. In this range, the dazzling light is glare, and the light emitted by our lamp is controlled beyond the cut-off angle greater than 30 degrees. So the glare is well controlled.

Description

Main body with radiant surface made of die-cast aluminium.

  • 3 sizes with 4 combinations, power from 8-15W each LED.
  • 15°/24°/36°beam angle options meet different light environment.
  • A wide variety of sizes and finishes that ensure a perfect integration in all environments. .
  • COB to front ring deep distance reach to 55mm,eyes can not see COB directly to ensure an excellent visual comfort.
  • UGR<16.
  • High visual,combines comfort, innovation, color and technology, which blends with unique savoir faire.
  • Installation without tools.
  • IP20

Additional information

Size

L88xW88xH70/85/100mm, L168xW88xH70/85/100mm, L247xW88xH70/85/100mm, L168xW168xH70/85/100mm

Cut-Out

L75*W75mm, L160*W75mm, L240*W75mm, L160*W160mm

Beam Angle

15°, 24°, 36°

Power

8/12/15W, 8/12/15W x2, 8/12/15W x3, 8/12/15W x4

Input

AC 200-240V

Reflector Color

Sandy Black, Sandy White, Bright Silver, Rose Gold, Gun Black
