Cherry

Non dimmable version is default, dimmable versions can be customized which are universally compatible with triac and 0-10V and DALI etc.

Description

Main body with radiant surface made of die-cast aluminium.

  • 4 sizes measurement design can reach to power from 12W to 40W.
  • 15°/24°/38° beam angle options meet different light environment.
  • White/black/sliver/golden anti-glare deep gleaming ring suitable office, hotel, home, dining, leisure, entertainment…scenes.
  • High-definition optics made of metallised thermoplastic material, emission with luminance control UGR<19.
  • The special configuration of the optical system delivers a precise circular distribution without punctiform effect.
  • High visual,combines comfort, innovation, color and technology, which blends with unique savoir faire.
    Installation without tools.
  • IP20, IP23 on the visible body of the mount after installation。

Additional information

Size

Φ95xH72mm, Φ110xH92mm, Φ140xH112mm, Φ160xH114mm

Cut-Out

Φ75mm, Φ95mm, Φ120mm, Φ140mm

Beam Angle

15°, 24°, 38°

Power

12W, 20W, 30W, 40W

Input

AC 200-240V

Color

White+Black
